TECHNICAL SPECIFICATION / ТЕХНИЧЕСКАЯ СПЕЦИФИКАЦИЯ | ||||||
Height (mm) высота |
Width (mm) ширина |
Center Distance (mm) Расстояние до центра |
Bars разделы |
BTU БТЕ |
Weight (kg) масса |
Finish цвет |
600 | 408 | 560 | 6*2 | 2036 | 14 |
anthracite white black антрацит белый черный |
600 | 612 | 560 | 9*2 | 3044 | 20 | |
600 | 748 | 560 | 11*2 | 3716 | 24 | |
600 | 884 | 560 | 13*2 | 4388 | 28 | |
600 | 1020 | 560 | 15*2 | 5060 | 32 | |
600 | 1156 | 560 | 17*2 | 5732 | 36 | |
600 | 1428 | 560 | 21*2 | 7076 | 44 | |
Elliptical Tube / Эллиптическая трубка :60*15mm Round Tube / Круглая трубка: 35mm |
PRODUCT FEATURES |
PRODUCT DESCRIPTION |
|
-High quality triple layered finish. -Made from 1.5mm premium mild steel. -Fully safety tested. -1/2" inlets and outlets. -Manufactured in accordance with BS EN 442 -Unique hot water circulation structure -Wall mount or stand-up installation -Come with 15 years warranty. -Brackets and fixings are included. -Can be used on all UK water heating systems. -Valves are not included. But can be bought separately. |
